AT-AM160S-01E
AT-AM160S-01E
Product name: 1.60inch AMOLED
Model No.: AT-AM160S-01E
Display COLOR： 16.7M
Viewing Direction： All
Interface： QSPI
Controller： RM69092/TMA520
Operating temperature： -20~+70℃
Brightness(cd/m²)： 450cd/m²
Touch Screen： With touch screen
Share to:
AT-AM160S-01E is a OLED module. It is composed of a OLED panel, driver IC and FPC unit,this product accords with ROHS environmental criterion.
| Item | Contents | Unit | Note |
| OLED Type | AMOLED | – | |
| Display color | 16.7M | ||
| Viewing Direction | ALL | O’Clock | |
| Operating temperature | -20~+70 | ℃ | |
| Storage temperature | -40~+80 | ℃ | |
| Module size | 28.92*33.35 | mm | |
| Active Area(W×H) | 27.02*30.4 | mm | |
| Number of Dots | 320*360 | dots | |
| Controller | RM69092/TMA520 | – | |
| Brightness | 450 | cd/m² | |
| Interface | QSPI | – | |
| Connector | 34 | pins | customizable |
| Size | 1.6 |
| Resolution | 320×360 |
| COLOR | Full Color |
| A.A.(mm) | 27.02×30.4 |
| Outline (mm) | 28.92×33.35 |
| Interface | SPI |
| IC | ICNA3311 |
